TITLE
LX455
GWVR
24000
DRY WEIGHT
19685
HITCH WEIGHT
3560
CARGO CAPACITY
4251
WIDTH
8'-5"
HEIGHT
13'-2"
LENGTH
46'-0"
SQFT
460
SLEEP CAPACITY
5-6
AXLES
3 x 8000
FRESH TANK
100
GREY TANK
75
BLACK TANK
100
WATER HEATER
12
FURNACE
40,000 BTU
AIR CONDITIONER
15,000 BTU
AIR CONDITIONER2
15,000 BTU
AIR CONDITIONER3
15,000 BTU
LP TANK CAPACITY
2 x 40 LBS
REFRIGERATOR
18 Cu Ft/110/Res.
CONVERTOR
80 AMP
SHORE POWER
50 AMP
NUMBER OF SLIDES
4
MAIN SLIDE HEIGHT
7'-3-1/2"
BEDROOM HEIGHT
6'-7-1/8"
AWNING LENGTH
17'
COOK TOP
4 Burner
TRADITIONAL OVEN
Yes
CONVECTION OVEN
Yes
GARAGE LENGTH
12'-0'
GENERATOR PREP
Optional
BED SIZE
King

Features

  • Goodyear® 17 1/2” H-Rated Re-Groovable Tires
  • Kodiak® Automotive Disc Brakes
  • Heavy Duty Axles
  • Commercial Grade E-Z Lube® Hubs
  • 15” Triple Stacked Box Tube Frame
  • 101” Wide Body
  • Industrial Hydraulic System for Jacks & Lower Level
  • Electric Bedroom Slide
  • Slide Outs w/Select Push Button Controls
  • 15″ Custom Triple Box Tube Frame
  • 101″ Wide Body Frame
  • Goodyear® 17 1/2″ H-Rated Tires
  • Automotive Disc Brakes
  • 8,000 lb. Rated Axles (triple axle models)
  • Heavy Duty 9,000 lb. Axles (tandem axle models)
  • 3 1/4″ Thick Walls with Foam Core
  • 100 Gallon Fresh Water Tank
  • 75 Gallon Gray Water Tank
  • 50 Gallon Black Water Tank
  • 12 Gallon Hot Water Heater
  • Heavy Duty Grease Bolt Shackles w/Bronze Bushing
  • Automotive Style Disc Brakes
  • Commercial Grade EZ Lube Hubs
  • 15″ Triple Stacked Box Tube Frame
  • 101″ Wide Body
  • Industrial Hydraulic System for Jacks & Lower Level Slides
  • Electric Bedroom Slide
  • Slide Outs w/Select Push Button Controls
  • Pinless, Industrial Hydraulic Front Landing Jacks at 5° Outboard Angle
  • 3″ Thick Floor
  • 14″ O.C. Floor Aluminum Floor Joists
  • Screwed & Glued Joist Construction
  • 5/8″ Tongue & Groove Plywood Flooring
  • Four Season Perimeter Heat Ducting in Floor
  • Residential Rated R29 Formaldehyde Free Insulation
  • 3 1/4″ Thick Walls/Slides
  • 16″ O.C. Stud Spacing
  • Screwed & Glued Aluminum Stud Construction
  • 1/4″ Monsanto® Fome-Cor Vapor Barrier (Eliminates Condensation)
  • 1/4″ Thick High Gloss Gelcoat Fiberglass
  • Azdel OnBoard Composite Panels
  • Residential Rated R16 Formaldehyde Free Insulation
  • 16″ O.C. Rafter Spacing
  • Residential Rated R25 Formaldehyde Free Insulation
  • 1/2″ Plywood Roof Overlayment
  • Seamless, 1-Piece Rubber Roof
  • Soft-Touch Vinyl Ceiling, Including Interior Slide-Out Ceilings
  • Straight Roof Line w/8′ Tall Interior Slide Out Height
  • Subzero Thermo- Pack High Density Insulation
  • High Gloss Gelcoat Fiberglass
  • High Gloss Gelcoat Fiberglass Molded Caps
  • Custom Painted Exterior w/Clear Coat
  • Frameless Tinted Safety Glass Windows
  • LED Back-Up Lights
  • Commercial LED Exterior Clearance Lights
  • Mid-Ship and Front Cap Turn Signal
  • LED Docking Lights
  • Dual 78″ Entry Door
  • Removable Storm Door Panels
  • Metal Slam Door Compartment Latches
  • Extra Thick Compartment Doors w/Gas Struts
  • Motion Sensor LED Lights in Basement
  • Custom Enlarged Control Center w/LED Lighting
  • Lend-a-Hand Exterior Grab Handle
  • Power Awning w/Aluminum Weather Shield (Over Both Entry Doors)
  • Water Pump Switch at Outside Hookup Center
  • 0 Amp Service w/Detachable Cord
  • 80 Amp 12 VDC Converter
  • 100 Gal. Fresh Water Tank
  • 75 Gal. Grey Water Tank w/Power Flush
  • 50 Gal. Black Water Tank w/Power Flush
  • SeeLevel Tank Monitoring System on All Tanks
  • Residential Type 1/2″ Water Lines
  • Exclusive Copper Water Manifold w/Individual Shut- Off Valves
  • Whole House Water Filtration System
  • Multi-Switch Water Bypass System
  • Slide Out Propane Tray w/Dual 40 Lb. Tanks
  • 12VDC Battery on Pull Out Tray
  • 40,000 BTU Furnace w/Custom Plenum
  • Residential 5 Duct Heating System w/6″ Ducting
  • Forced Heat Ducting to Tanks/Water System
  • Fully Ducted A/C System w/Cold Air Return
  • Triple 15,000 BTU Low-Profile A/Cs
  • Solar Prep
  • HD Roof Satellite Prep for Dual DVR Receivers
  • HD Ground Satellite & Cable Prep
  • HD TV Antenna
  • Hand Laid Vinyl Floor Tile
  • Residential Rebond Carpet Pad
  • Plush Residential High Durability Carpet
  • Solid Hardwood Cabinetry
  • Interior Ceiling Fan (Most Models)
  • Solid Hardwood Fascia Trim Around Slide Outs
  • Solid Hardwood Cabinet Stiles (Pocket Drilled/Screwed)
  • Concealed Cabinet Door Hinges
  • Raised Panel Cabinetry
  • Soft-Close Full Extension Metal Drawer Guides
  • LED Interior Ceiling Lighting on Dimmer Switches
  • Utility Closet w/Coat Storage & Centralized Control Station
  • Custom Hardwood Dinette Buffet w/Solid Surface Top (Some Models)
  • Dinette Table w/Hidden Leaf Extension (Some Models)
  • (2) Hardwood Dinette Chairs w/Fabric Accent (Some Models)
  • Crown Molding Throughout
  • HD Wiring Throughout
  • 20 Cu. Ft. Residential Stainless Steel French Door Refrigerator
  • Pull-Out 13 Gal. Garbage Can
  • Stainless Steel Convection/Microwave
  • Deep Double Bowl Stainless Steel Sink w/Sink Covers
  • Residential Kitchen Faucet w/Sprayer
  • High Polished Solid Surface Countertops
  • Residential Style Stainless Steel Range
  • Custom Appliance Garage w/Pull-Out Tray (Most Models)
  • Lighted Pantries & Kitchen/Bathroom Toe Kicks
  • Hardwood Steps
  • Hand Laid Vinyl Tile Throughout
  • Washer/Dryer Prep
  • Heat & A/C Ducting in Bathroom
  • Maxxair® Fan in Bathroom
  • Custom Fiberglass Shower Pan with Custom Shower Surround
  • Sky-Light Over Shower w/LED Pot Light
  • Porcelain Toilet w/Water Saver Spray
  • Macerator Toilet (Some Models)
  • Custom Walk-in Front Closet w/Built in Dresser (Most Models)
  • Real Cedar Lined Front Closet
  • Custom Hardwood Wardrobe Doors
  • King Bed Suite 72″ x 80″ w/Innerspring Mattress
  • Full Storage Under Bed Base
  • 32″ TV with Built in Soundbar
  • Dimmable Over the Bed Reading Lights on Separate Switches
  • Vanity Slide
  • Industrial Metal Overhead Cabinetry
  • LED Lighting
  • 50″ LED HD TV
  • Touch Screen/Blue Tooth Garage Audio/Ent. System
  • Dual 30 Gal. Fuel Tanks w/Fuel Pump & Fill Station
  • 55″ LED TV & Home Theatre Package
  • 32″ LED Bedroom TV Package
  • 50″ LED TV Garage
  • Garage Ent. System w/Touch Screen
  • Goodyear® 17 1/2″ H-Rated Spare Tire
  • Side Mounted Fold-Out Ladder
  • Frameless Thermopane Windows
  • Dual Door 4-Step Entry
  • MCD Day/Night Roller Shades
  • Built-In Fireplace
  • Magnum 1000W Inverter w/Dual 6V Batteries
  • Maxxair® Fan w/Rain Sensor – Bathroom
  • Maxxair® Fan w/Rain Sensor – Kitchen
  • Power Mgmt. System
  • Six Point Hydraulic Leveling System
  • One Touch Auto Leveling
  • Keyless Entry Door (Both Doors)
  • Onan 5.5 Gasoline Generator w/Auto Gen. Start

Options

Interior:

  • Power Recliner Theatre Seating/Recliners
  • Folding Chair based on interior color



Entertainment:

  • 32″ LED HDTV Outdoor Ent. (Some Models)
  • Winegard® Trav’ler HD Auto Satellite
  • WiFi Ranger Wireless Router



Bedroom:

  • Built in Front Wardrobe Safe w/Keyless Entry
  • Queen Bed Suite



Garage:

  • Electric Drop Down Sofa/Bed
  • Electric Drop Down Bed
  • Fold-Up Outdoor Patio
  • 3 Season Patio Door
  • Removable Table



Systems/Vents/Fans

  • RV Halo™ Voice AI Enabled Assistant
    Brochure – Quick Start Guide
  • Heat Pump
  • Maxxair® w/Switch Control – Garage
  • Splendide® Front Load 2 Piece
  • Splendide® XC 2,100 Combo



Construction/Running Gear

  • Power Cord Reel (Some Models)
  • HBA Brake Cam (To be Ordered Special for Customers w/GM Trucks)



Exterior/Awnings:

  • Slide Toppers
  • Power Dinette Slide Awning w/Weathershield
  • Slide Out Storage Tray (36″ x 90″)
  • Audible Wireless Backup Camera System
  • CSA



Partial Body Paint:

  • Glacier Bay
  • Mystic Reserve
  • Regal Heights
